Multi-Phase Project: Phase
North Shore Connector Aerial Structure
Completion of this project further extends Allegheny County’s Light Rail System from underneath downtown Pittsburgh and the Allegheny River to the North Shore.
location
Pittsburgh
,
Pennsylvania
ESTIMATED VALUE
$40.8M
owner
Pittsburgh Port Authority
Completion date
12/2010
general contractor
Brayman Construction Corporation
Market
Transportation
Multi-Phase Project: Phase
North Shore Connector Aerial Structure
The Port Authority of Allegheny County awarded Brayman the North Shore Connector Aerial Structure, Retained Fill and Demolition of the Miller Printing Building Contract (NSC-007). Completion of this project further extends Allegheny County’s Light Rail System from underneath downtown Pittsburgh and the Allegheny River to the North Shore. Project includes construction of a 1,755lf dual 14-span tub girder aerial structure along Reedsdale Street in Pittsburgh, PA.
